Garrett G25-660 Turbocharger 877895-5010S

Product number: 877895-5010S
Garrett Turbocharger
  • up to 660 HP
  • Reverse Rotation
  • Ball bearing
  • Compressor wheel Ø 54mm

€2,121.73

Prices excl. VAT plus shipping costs

Delivery 5 to 8 days

icon/general/ico_circle_check-inner
Worldwide shipping
icon/general/ico_circle_check-inner
Shop safely
icon/general/ico_circle_check-inner
Certified Online Shop
icon/general/ico_circle_check-inner
Made for High-Boost
Quick Links
Group 2 Flange Diagram
Group 6 Authorized Dealer
Description

Power Rating: 300-660 HP
Displacement: 1.4 - 3.0 L
V-Band Inlet - V-Band Outlet - Single Scroll - Internal Wastegate - A/R 0.92

Garrett G-Series - The newest and most advanced generation turbocharger!

These very small turbochargers achive extremely high performance with minimum space requirements.

Features:

  • Latest CFD-optimised, forged milled compressor wheel
  • High-Flow compressor housing with integrated easy plug speed sensor port
  • Rotation: Reverse (Counterclockwise)
  • Dual ceramic ball bearing cartridges
  • Includes -4AN oil restrictor fitting with 1mm orifice
  • Four large water jacket ports
  • Twin piston rings at compressor and turbine site
  • MAR-M 1050°C Turbine wheel
  • Water- and Oil cooled
  • Internal Wastegate
  • Turbine Housing: V-Band Inlet, V-Band Outlet
  • Compressor side: Inducer Ø 54mm / Exducer Ø 67mm
  • Turbine side: Inducer Ø 54mm / Exducer Ø 49mm
  • Delivery: Turbocharger, 0.5 bar Actuator, 2 x -6AN water fittings and two plugs, 1 x Oil restrictor -4AN

Buy from us, the only Garrett Performance distributor in Germany!Your best choice for quality and service for over 30 years!
