2.0L TSI EA888 V1 upgrade Turbocharger K04 up to 400 HP Turbo-Total®

Product number: 21tf196

€2,015.09

Prices excl. VAT plus shipping costs

Available, delivery time: 1 - 3 days

icon/general/ico_circle_check-inner
Worldwide shipping
icon/general/ico_circle_check-inner
Shop safely
icon/general/ico_circle_check-inner
Certified Online Shop
icon/general/ico_circle_check-inner
Made for High-Boost
Quick Links
Group 6 Authorized Dealer
Description

V1 K04 upgrade Turbocharger from Turbo-Total® up to 400 HP for 2.0L TSI EA888 engines with chain.

With our V1 upgrade turbocharger you replace the small original BorgWarner turbo and can reach an engine power up to 400hp. Matching components like exhaust system with Downpipe, high pressure pump, injectors and matching software tuning are needed for 400 HP.

This is what our V1 upgrade turbocharger has to offer

  • Upgrade K04 supercharger
  • Milled compressor impeller with perfectly optimized geometry
  • Reinforced 360° support for even more durability
  • Reinforced pressure can, so no flutter and always a stable charge pressure
  • Turbocharger was balanced to smallest tolerances
  • Adapted pressure side for EA888 chain engine
  • Closure for crankcase ventilation
  • The turbocharger is a new part, no exchange or remanufactured charger
  • Plug&Play fit in 2.0L TSI EA888 engines
  • New gasket, stud bolt and copper nuts are included for free!

Delivery complete with manifold, pressure can and boost pressure control valve.

We recommend at least the oil supply line to renew with!

Suitable for:

  • 2.0L TSI EA888 engines with engine codes: CAWB, CCZA and CCZB.

Our V1 upgrade turbocharger is based on KKK K04 and is therefore plug&play to the TSI typical downpipes, intake as well as pressure lines fit.

Blue coating of the manifold is not included in the price:

Better than any heat tape is the ceramic coating.
The process is still applied by hand individually on each component.
All kinds of components such as manifolds or turbocharger exhaust turbines can be coated.
First a base coating in beige color is applied.
After that up to 14 different colors can be chosen.
The price is calculated according to effort and color and starts at 250 euros upwards.

Advantages of Plasma Ceramic coating:

  • Better properties than ordinary heat tape
  • Durable up to approx. 900°C
  • Reduction of surface temperature by approx. 33
  • Up to 50°C lower engine compartment temperature
  • High effect with low weight (0.3mm thickness)
  • More effective engine performance and life
  • Improves "spool up" (acceleration) of the turbocharger
  • Faster cooling of the entire engine
  • 3 years warranty (Ceramic coating only clean with soap, no brake cleaner!)
  • Choice of 14 different colors.

(No exchange necessary)

Do you have questions about the product? Just start the chat, we will help you with your product selection.
direct reply in chat
Fits for
Engine Engine code
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
Engine Engine code
2.0 TFSI (EA888) CCTA | 200 PS (147 kW)
2.0 TFSI (EA888) CCZC | 170 PS (125 kW)
2.0 TFSI (EA888) CPSA | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
2.0 TFSI (EA888) CESA | 211 PS (155 kW) - CA und USA
2.0 TFSI (EA888) CETA | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
Engine Engine code
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZ | 211 PS (155kW)
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
Engine Engine code
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
Engine Engine code
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCTB | 170 PS (125 kW)
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
Engine Engine code
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
Engine Engine code
2.0 TFSI (EA888) CAWA | 170 PS (125 kW)
2.0 TFSI (EA888) CCTA | 200 PS (147 kW)
2.0 TFSI (EA888) CCTB | 170 PS (125 kW)
2.0 TFSI (EA888) CCZA | 200 PS (147 kW)
2.0 TFSI (EA888) CCZB | 211 PS (155 kW)
2.0 TFSI (EA888) CCZC | 170 PS (125 kW)
2.0 TFSI (EA888) CCZD | 180 PS (132 kW)
